Extrusion machines for T-fittings

TTEngineering offers dedicated extrusion machines specifically designed for the efficient and precise production of T-fittings, critical components used to branch airflow in HVAC, ventilation, and chimney systems.

These machines enable manufacturers to achieve excellent dimensional accuracy and smooth surface finishes, minimizing the need for secondary processing and ensuring optimal performance and aerodynamic efficiency in the final application.

MT3 extrusion machine

The MT3 is a compact and versatile extrusion machine engineered for the production of T-fittings with diameters ranging from 60 mm to 400 mm and wall thicknesses between 0.4 mm and 1.0 mm. It supports pipe lengths of up to 1,550 mm and delivers fast cycle times of approximately 15 seconds per piece, making it an excellent choice for high-volume production environments where efficiency and repeatability are essential.

Equipped with an adaptable tooling system, the MT3 enables quick diameter changes with minimal downtime, allowing manufacturers to respond efficiently to diverse production requirements.

This model is particularly well-suited for standard HVAC and ventilation applications, where medium-sized T-fittings are widely used to ensure balanced and efficient air distribution across systems.

ERX extrusion machine

The ERX is engineered for the production of large-diameter T-fittings, covering sizes from 80 mm to 870 mm and wall thicknesses from 0.4 mm to 2.0 mm. Like the MT3, it supports pipe lengths up to 1,550 mm, but is specifically designed to process larger and heavier sections, delivering cycle times of approximately 20 seconds per piece.

This robust machine is ideal for heavy-duty HVAC systems, industrial ventilation networks, and chimney installations that require structurally strong and precisely formed T-branches. The ERX combines high forming power with accurate, repeatable performance, enabling manufacturers to produce large-scale fittings while ensuring structural integrity and optimal airflow characteristics.

Both the MT3 and ERX are equipped with quick-change, personalized tooling systems, which streamline setup operations and minimize maintenance-related downtime. TTEngineering’s extrusion solutions empower manufacturers to achieve consistent product quality, maximize production capacity, and reduce overall operational costs.

For more information, please contact TTEngineering through the references available on its online booth.
